10 FT Single Drum Mine Hoist FOR SALE

Single Drum Mine hoist WinchID# H095

OVERVIEW

10ft Hoist, Nordberg Single Drum Hoist, 500hp Motor, 120'' diameter, 50'' Face, 6 1/2'' Flange Depth, Rope Cassete Grooving Spiral Groove, Brake system: Caliper Drum Type Pararell Brakes,Medium Pressure Hydraulics Composite wearpads, counterweight to set, hydraulics torelease, Deum Speed 23.38 RPM, Cable 1 3/8 Brand new Spare Rope with certs, Speed with existing motor 734 ft/min or 1,000ft/min with 800hp Dc motor and new drive, Rim Pull: 22,500lbs, Date 1970, depth of use at Prev Project: 1,800ft

ID# H095.

10ft Hoist, Nordberg Single Drum Hoist, 500hp Motor, 120'' diameter, 50'' Face, 6 1/2'' Flange Depth, Rope Cassete Grooving Spiral Groove, Brake system: Caliper Drum Type Pararell Brakes,Medium Pressure Hydraulics Composite wearpads, counterweight to set, hydraulics torelease, Deum Speed 23.38 RPM, Cable 1 3/8 Brand new Spare Rope with certs, Speed with existing motor 734 ft/min or 1,000ft/min with 800hp Dc motor and new drive, Rim Pull: 22,500lbs, Date 1970, depth of use at Prev Project: 1,800ft

QUANTITY AVAILABLE (1).

Location: Miami, Arizona.
